Description

The 631 meets the 2024 US Access Board standard with a 17" low seat height. See what the standard requires →
The Midmark 631 is a power procedure chair built for in-office procedures and for patients of every ability. It lowers to 17" so patients can transfer from a wheelchair with little or no help, then rises to 39" and moves through 8-way powered positioning to put the patient exactly where the clinician needs them.
Patient Accessibility
- 17" low / 39" high seat height, meeting the 2024 US Access Board Standards for Accessible Medical Diagnostic Equipment.
- 28" wide x 19.5" deep transfer surface; 19" base works with patient lifts.
- Optional Patient Support Rails and Articulating Knee Crutches provide the transfer and leg supports the standard calls for.
Procedure Positioning
- 8-way powered positioning with Motion Profiling® for smooth, natural movement.
- Active Sensing Technology® stops chair movement on contact.
- Extendable footrest; supports procedures from head and neck to lower extremity.
- Wide range of headrests, armboards, rails and trays to set up the chair for your specialty.
Configurations
- #631-001: Non-Programmable, Wired Hand/Foot Controls, Includes Hospital-Grade Receptacles.
Standard with every chair: paper roll holder, debris tray, stirrups, and wired hand and foot controls.
Colors
Standard Upholstery Colors
UltraFree* Upholstery Colors
*Ultraleather® by Ultrafabrics®
On-screen colors can differ from the actual material, and suppliers may change colors. Ask us for a physical sample to confirm your selection before ordering. Midmark upholstery color guide (PDF)
Accessories
Upholstery top upgrades, chair arms, headrests, Patient Support Rails and Rails+, articulating knee crutches, armboards, accessory rails, instrument trays, IV pole, security side panels and straps, locking casters and spare hand/foot controls are listed under Recommended accessories below, each with its own page and quote button. View all Midmark 631 accessories →
Technical Specifications
| Patient weight capacity | 650 lb (294 kg) |
| Seat height | 17" low / 39" high |
| Transfer surface | 28" W x 19.5" D (32" wide top optional) |
| Support surface length | 71"–75" in flat position |
| Positioning | 8-way powered, Motion Profiling®, Active Sensing Technology® |
| Receptacles | Hospital-grade duplex outlets each side (115 VAC, 3 A) |
| Electrical | 115 VAC, 60 Hz, 12 A |
| Standard features | Paper roll holder, debris tray, stirrups, wired hand and foot controls |
Resources
- Midmark 631 product page
- Midmark upholstery color guide (PDF)
- US Access Board standards brief (PDF)
- Patient Support Rails brochure (PDF)
Pricing: Contract and volume pricing available, including Vizient and Provista. Add the chair to your quote with your upholstery color and any upgrades or accessories and we'll get back to you with pricing and lead time.
Compare Midmark procedure and podiatry chairs →
Your selected configuration
Our chair quotes include standard upholstery in your selected color. Optional upgrades and accessories are quoted separately.
