Description
Overview
The Welch Allyn Green Series 777 Wall Transformer (77710) is the wall-mounted power base of the GS 777 diagnostic system, without instrument heads. It lets a facility build its own wall setup by choosing the otoscope, ophthalmoscope or other 3.5 V heads separately.
Key Features
- Handle-activated power: lifting a handle from its cradle turns that instrument on and returning it turns it off, which saves energy and lamp life.
- Handle-based rheostats adjust light intensity with one hand.
- Modular coiled cords, 12 ft extended, built for daily exam-room use.
- Choose your own Welch Allyn 3.5 V heads, including wide-view PanOptic or traditional ophthalmoscopes and MacroView or standard otoscopes.
Configuration and Package Contents
- Part number 77710 (GTIN 00732094136906): Green Series 777 wall diagnostic system, instrument heads not included (order separately).
- North American power: 100–240 V, 50–60 Hz AC, IEC plug type B.
- Instrument heads sold separately.
Technical Specifications
| Instrument power | Powers Welch Allyn 3.5 V instruments; one instrument powered at a time |
| Electrical input | 100–240 V AC, 50–60 Hz |
| Output | 5 V DC |
| Coiled cords | 12 ft extended |
| Operating environment | 59–104 °F (15–40 °C), 15–95% relative humidity |
| Materials | ABS and elastomer rubber, non-latex |
| Safety class | Class II, intermittent operation |
Compatibility and Accessories
- Instrument heads: PanOptic Plus Ophthalmoscope (118-3-US), MacroView Plus Otoscope for iExaminer (238-3), MacroView Basic Otoscope (238-2)
- Power cord kit: Green Series 777 Wall System Power Cord, US (PWCD-GS777-B)
- Version with aneroid and dispenser: GS777 Wall System, No Heads, with Specula Dispensers and Wall Aneroid (77910)
Documents and Warranty
- Welch Allyn GS 777 Wall Transformer instructions for use (PDF)
- Green Series 777 Integrated Wall Systems and Transformers flyer (PDF)
- Green Series 777 Integrated Wall System product page (Baxter)
- 77710 catalog page (Baxter catalog)
- Warranty: the GS 777 wall transformer carries a 5-year limited warranty (GS 777 IFU).
Compare Models
- 777-PM2XXX-US: same transformer with PanOptic Basic and MacroView Basic heads.
- 777-PM3XXX-US: same transformer with PanOptic Plus, MacroView Plus for iExaminer and SmartBracket.
- 777-SM2XXX: same transformer with coaxial LED ophthalmoscope and MacroView Basic.
