Description
Overview
The ConMed ThermoGard® 51-7710 is a single-use pediatric dual-foil dispersive (patient return) electrode for monopolar electrosurgery. It is coated with ConMed's blue hydrogel for good contact with the patient's skin and is sized for pediatric patients weighing 5–15 kg (11–33 lb). The 10 ft cable comes pre-attached.
Key Features
- Blue hydrogel is designed for quality contact with the patient's skin while remaining gentle
- Dual-foil pad design
- Pediatric size for patients 5–15 kg
- Pre-attached 10 ft (3.05 m) cable, ready to connect
- Single-use, individually packaged pads
Configuration and Package Contents
- Catalog # 51-7710
- 80 electrodes per case, 1 per package
- Cable: 10 ft (3.05 m), pre-attached
Technical Specifications
| Type | Pediatric dual-foil |
| Patient weight | 5–15 kg (11–33 lb) |
| Cable | 10 ft (3.05 m), pre-attached |
| Conductive medium | Blue hydrogel |
| Use | Single use |
| Quantity | 80 per case (1 per package) |
Compatibility and Accessories
- For argon beam coagulation, ConMed offers ThermoGard Plus ABC dispersive electrodes, designed for use with ConMed ABC
- Active accessories: ConMed GoldLine push button pencils
Documents and Warranty
- ConMed ThermoGard® and dispersive electrodes product page
- ConMed ThermoGard® product brochure (PDF)
- ConMed Advanced Surgical Product Catalog (PDF)
Compare Models
| Catalog # | Type | Patient weight | Cable |
| 51-7310 | Adult dual-foil | >15 kg (33 lb) | 10 ft (3.05 m), pre-attached |
| 51-7410 | Adult dual-foil | >15 kg (33 lb) | None; uses reusable cable T229 |
| 51-7810 | Adult single-foil | >15 kg (33 lb) | 10 ft (3.05 m), pre-attached |
| 51-7710 | Pediatric dual-foil | 5–15 kg (11–33 lb) | 10 ft (3.05 m), pre-attached |
| 7-382 | ThermoGard Plus ABC® adult dual-foil (for argon beam coagulation), 40/case | >15 kg (33 lb) | 10 ft (3.05 m), pre-attached |
Genuine ConMed product, sold by The Hospital Equipment Company.
