Description
Overview
The ConMed MacroLyte adult single-foil dispersive electrode is a single-use electrosurgical patient return pad for patients >15 kg. MacroLyte is ConMed’s cost-effective dispersive electrode line; this version has no cable and connects to the generator through a reusable ConMed cable.
Key Features
- Adhesive hydrogel holds the pad in place on the patient’s skin
- Thin foam backing conforms to the body for consistent skin contact
- Scalloped edges help the pad follow body contours
- Single-use pad, so there is no cleaning or reprocessing between patients
Configuration and Package Contents
- ConMed catalog # 400-2349
- Adult, single-foil pad, for patients >15 kg
- No cable: use ConMed reusable cable T229 (sold separately)
- Sold by the case: 100 electrodes per case (50 per box, 1 per package)
- Single use
Technical Specifications
| Catalog number | 400-2349 |
| Product line | MacroLyte |
| Patient size | Adult |
| Foil configuration | Single |
| Patient weight | >15 kg |
| Cable | None; uses reusable cable T229 |
| Packaging | 100/case, 50/box, 1/package |
| Use | Single use |
| Packaged sterile | No |
Compatibility and Accessories
- Requires ConMed reusable cable T229 per ConMed’s ordering guide: ConMed T229 reusable dispersive electrode cable, 10 ft or the longer T229-5M version
- ConMed MacroLyte adult single dispersive electrode, 10 ft cable (400-2100)
- ConMed SureFit dual dispersive electrode, 10 ft cable (410-2000)
- ConMed ThermoGard adult dual dispersive electrode, 10 ft cable (51-7310)
Documents and Warranty
- ConMed MacroLyte, SureFit and ThermoGard dispersive electrodes product page
- ConMed SureFit and MacroLyte dispersive electrodes brochure (PDF)
Compare Models
| Model | Type | Patient weight | Cable | Per case |
| 400-2349 | Adult single | >15 kg | None (reusable cable T229) | 100 (50/box) |
| 400-2100 | Adult single | >15 kg | 10 ft (3.05 m), pre-attached | 100 (25/box) |
| 425-2200 | Pediatric single | 5–15 kg | 10 ft (3.05 m), pre-attached | 100 (25/box) |
| 425-2508 | Pediatric dual | 5–15 kg | 10 ft (3.05 m), pre-attached | 100 (25/box) |
| 450-2300 | Infant single | Contact us to confirm | 10 ft (3.05 m), pre-attached | 60 (15/box) |
| 440-2400 | Premie single | <5 kg | 10 ft (3.05 m), pre-attached | 40 (10/box) |
Genuine ConMed product, sold by The Hospital Equipment Company.
