Description
Overview
This is a replacement flow sensor for the ndd EasyOne Pro and EasyOne Pro LAB pulmonary function systems. It uses ndd's ultrasonic transit-time TrueFlow measurement, which has no moving parts in the flow path and does not need calibration during its lifetime. Order it to replace a damaged sensor and return the system to service.
Key Features
- Ultrasonic transit-time measurement gives contact-free, resistance-free flow sensing with accuracy independent of gas composition, pressure, temperature and humidity.
- No calibration required during its lifetime, so routine work is limited to optional syringe cal-checks.
- Low resistance (<1.5 cm H2O/L/s at 14 L/s) keeps the sensor from affecting patient effort during testing.
- Same part for EasyOne Pro and Pro LAB.
Configuration and Package Contents
- One ndd flow sensor, part number 3000-50.5.
- Single-use Spirette mouthpieces and Barriettes sold separately.
Technical Specifications
| Part number | 3000-50.5 |
| Measurement principle | Ultrasonic transit time |
| Flow range | ±16 L/s |
| Flow resolution | ≤1 mL/s |
| Flow accuracy (except PEF) | ±2.5% or 0.02 L/s |
| PEF accuracy | ±5% or 0.200 L/s |
| Volume accuracy | ±2.5% or 0.050 L |
| MVV accuracy | ±5% or 5 L/min |
| Resistance | <1.5 cm H2O/L/s at 14 L/s |
Compatibility and Accessories
- Fits the ndd EasyOne Pro (3000-1) and ndd EasyOne Pro LAB (3100-1).
- Testing consumables: ndd Spirette Mouthpieces and ndd DLCO Barriettes.
- Optional cal-checks: ndd 3-Liter Calibration Syringe (2030-2) with the Spirette Calibration Adapter (2030-3).
Documents and Warranty
- ndd EasyOne Pro LAB factsheet with flow sensor specifications (PDF)
- ndd EasyOne Pro/LAB brochure (PDF)
- ndd ordering information (lists the flow sensor as a standard component)
- ndd manuals download page (EasyOne Pro-LAB Operator's Manual)
Genuine ndd product, sold by The Hospital Equipment Company.
